Only 1 left

CISCO

CISCO WS-C2960X-24PS-L, Catalyst 2960-X 24 GigE PoE 370W, 4 x 1G SFP, LAN Base

SKU WS-C2960X-24PS-L
$786
$786

Category: Network Switches

Condition: New

Incoterms: Ex-Works Singapore

  • FREE TECH SUPPORT

    With us, IT procurement becomes a seamless experience

  • EXCLUSIVE SERVICE

    Register to get 24 hrs services

  • ORDER TRACKING

    Don't know the progress of your order?

  • GROW WITH US

    Become part of our vibrant community

Product Description

Condition : NEW

Vendor Part Number : WS-C2960X-24PS-L

Category : Network Switches

Brand : CISCO

Product Type : Switch & Hub Components

Description : Catalyst 2960-X 24 GigE PoE 370W, 4 x 1G SFP, LAN Base

Cisco® Catalyst® 2960-X Series Switches are fixed-configuration, stackable Gigabit Ethernet switches that provide enterprise-class access for campus and branch applications (Figure 1). Designed for operational simplicity to lower total cost of ownership, they enable scalable, secure and energy-efficient business operations with intelligent services and a range of advanced Cisco IOS® Software features.

- 24 or 48 Gigabit Ethernet ports with line-rate forwarding performance.
- Gigabit Small Form-Factor Pluggable (SFP) or 10G SFP+ uplinks.
- FlexStack Plus for stacking of up to 8 switches with 80 Gbps of stack throughput (optional).
- Power over Ethernet Plus (PoE+) support with up to 740W of PoE budget.
- Reduced power consumption and advanced energy management features.
- USB and Ethernet management interfaces for simplified operations.
- Application visibility and capacity planning with integrated NetFlow-Lite.
- LAN Base or LAN Lite Cisco IOS® software features.
- Enhanced limited lifetime warranty (E-LLW) offering next-business-day hardware replacement.

Dimensions :

Weight 7.03 (KG)
Height 18.0 (CM)
Length 49.0 (CM)
Width 56.0 (CM)



Range Switches & Bridges
Part No. WS-C2960X-24PS-L
Model Cisco Catalyst 2960X-24PS-L Ethernet Switch - 24 Ports - Manageable - 4 x Expansion Slots - 10/100/1000Base-T - 24, 4 x Network, Expansion Slot - Twisted Pair - Gigabit Ethernet - 4 x SFP Slots - 2 Layer Supported - Power Supply - Redundant Power Supply - 1U High - Rack-mountable, DesktopLifetime Limited Warranty



Overview
General Information
Manufacturer Cisco Systems, Inc
Manufacturer Part Number WS-C2960X-24PS-L
Manufacturer Website Address http://www.cisco.com
Brand Name Cisco
Product Line Catalyst
Product Series 2960-X
Product Model 2960X-24PS-L
Product Name Catalyst 2960X-24PS-L Ethernet Switch
Marketing Information

Catalyst 2960-X series Software Features

All Catalyst 2960-X Series Switches use a single Universal Cisco IOS Software Image for all SKUs. Depending on the switch model, the Cisco IOS image automatically configures either the LAN Lite, LAN Base, or IP Lite feature set.

LAN Lite models have reduced functionality and scalability for small deployments with basic requirements. Cisco Catalyst 2960-X Family of Switches are available with the LAN Base and LAN Lite feature sets and Catalyst 2960-XR Family of switches are available IP Lite feature sets.

Note that each switch model is tied to a specific feature level; LAN Lite cannot be upgraded to LAN Base and LAN Base cannot be upgraded to IP Lite.
Product Type Ethernet Switch

Features & Specifications
Interfaces/Ports
Total Number of Network Ports 24
Token Ring Port No
LRE Port No
Bypass No
Modular No
Management Port Yes
USB Yes
Number of PoE (RJ-45) Ports 24
Port/Expansion Slot Details 24 x Gigabit Ethernet Network
Port/Expansion Slot Details 4 x Gigabit Ethernet Expansion Slot



Media & Performance
Media Type Supported Twisted Pair
Twisted Pair Cable Standard Category 5
Ethernet Technology Gigabit Ethernet
Network Technology 10/100/1000Base-T



I/O Expansions
Number of Total Expansion Slots 4
Expansion Slot Type SFP
Shared SFP Slot No
Number of SFP Slots 4



Network & Communication
Layer Supported 2



Management & Protocols
Manageable Yes
Management
  • Web-based Management
  • VLAN
  • QoS
  • Syslog
  • Telnet
  • RMON I, II
  • SNMP v1, v2c, v3
  • CLI
  • DHCP



Memory
Standard Memory 512 MB
Memory Technology DRAM
Flash Memory 128 MB



Reliability
MTBF 324280 Hour



Power Description
PoE (RJ-45) Port Yes
Input Voltage 110 V AC
Input Voltage 220 V AC
Power Source Power Supply
Redundant Power Supply Yes



Physical Characteristics
Compatible Rack Unit 1U
Form Factor Rack-mountable
Form Factor Desktop
Height 1.8"
Width 17.5"
Depth 14.5"
Weight (Approximate) 12.80 lb



Miscellaneous
Certifications & Standards IEEE Standards:
  • 802.1D
  • 802.1p
  • 802.1Q
  • 802.1s
  • 802.1w
  • 802.1X
  • 802.1ab
  • 802.3ad
  • 802.3af
  • 802.3at
  • 802.3ah
  • 802.3x
  • 802.3
  • 802.3u
  • 802.3ab
  • 802.3z
  • 802.3az
  • 802.1ae
  • 802.3ae
  • 802.1ax
Safety:
  • UL 60950-1 Second Edition
  • CAN/CSA-C22.2 No. 60950-1 Second Edition
  • EN 60950-1 Second Edition
  • IEC 60950-1 Second Edition
  • AS/NZS 60950-1
EMC:
  • 47CFR Part 15 (CFR 47) Class A
  • AS/NZS CISPR22 Class A
  • CISPR22 Class A
  • EN55022 Class A
  • ICES003 Class A
  • VCCI Class A
  • EN61000-3-2
  • EN61000-3-3
  • KN22 Class A
  • CNS13438 Class A
  • EN55024
  • CISPR24
  • EN300386
  • KN24
Green Compliant Yes
Green Compliance Certificate/Authority RoHS



Warranty
Limited Warranty Lifetime



Options & Accessories
Item Part Number Manufacturer Category Description
N/A CON-SNT-WSC224SL Cisco Systems, Inc Services US ONLY NBD 8X5 SMARTNET CAT2960-X 24GBE
N/A CON-3SNT-WSC224SL Cisco Systems, Inc Services 3YR SMARTNET 8X5XNBD CAT2960-X 24 G
